Quality assurance wm210V mini machine tools manual lathe for turning metal mini mechanical lathe
Item NO.: 20382979
Detail | FAQ
- Model Number:WM210V
- Brand Name:Huisn
- Swing Over Bed:210 mm
- Swing Over Cross Slide:140 mm
- Distance Between Centers:400 mm
- Width of Bed:100 mm
- Spindle Bore:38 mm
- Spindle Taper:MT5
- Number of Spindle Speeds:Variable
- Range of Spindle Speeds:50-2500 rpm
- Number of Metric Threads:14
- Range of Metric Threads:0.3-3 mm
- Number of Imperial Threads:10
- Range of Imperial Threads:10-44 T.P.I
- Range of Longitudinal Feed:0.1-0.2mm/R
- Tool Post Type:4
- Tailstock Taper:MT2
- Max Cross Slide Travel:55mm
- Max Compoud Slide Travel:75mm
- Max Carriage Travel:376mm
- Motor:750W 220V/110V
- N/W :75kg
- G/W:80kg
- Packing Size:900*450*450 mm
- Port：SHANGHAI/NINGBO
- Customized logo(Min. order 5 pieces)
- Customized packaging(Min. order 5 pieces)
- Graphic customization(Min. order 5 pieces)
- Lead time:1 piece = 7days，Between 2 to 10 pieces =20 days， >10 pieces=To be negotiated
